Khoom Taw Qhia
FC-2GB Siv los ntsuas DC qhov tsis sib xws ntawm Oxide Zinc arrester (voltage-dependent resistor), cermet thib ob, thiab thib peb electrode discharge tube, lub tshuab nqus tsev xob laim, thiab lwm yam khoom tiv thaiv dhau-voltage. FC-2GB ntsuas hluav taws xob tiv thaiv hluav taws xob tuaj yeem siv los ua qhov hluav taws xob ruaj khov, lub zog hluav taws xob tsis tu ncua, kev tiv thaiv hluav taws xob tiv thaiv hluav taws xob yog dav siv hauv hluav taws xob, hluav taws xob, thiab kev sib txuas lus. FC-2GB hluav taws xob tiv thaiv tiv thaiv ntsuas ntsuas muaj lub luag haujlwm ntawm lub cim xeeb, kev ua haujlwm, khaws cia, ntsuas tus kheej, lub tswb nrov, tiv thaiv hluav taws xob luv luv, tiv thaiv overcurrent, high voltage preset, thiab lwm yam
Khoom Parameter
1. Voltage dependent resistor ntsuas
|
Technical Specifications |
Kev ntsuas ntau |
Qhov yuam kev ntau kawg |
Kev Xeem |
|
Qhov hluav taws xob (U 1mA) |
(0-1999)V |
Tsawg dua lossis sib npaug ± 1% ± 1d |
1mA ± 5μA |
|
Cov dej ntws tam sim no (I 0.75U 1mA) |
(0.1 - 199.9 ) μA |
± (2 μA +1d) |
0.75 U1mA |
|
Tsawg dua lossis sib npaug ± 2% ± 1d |
2. Kev ntsuas lub raj xa dej
|
Technical Specifications |
Kev ntsuas ntau |
Qhov yuam kev ntau kawg |
Kev Xeem |
|
DC tawg voltage (V sdc) |
(5-1999)V |
Tsawg dua lossis sib npaug ± 1% ± 1d |
Tus nqi ntawm voltage nce |
|
100V/S±10% |
3. Lwm yam tsis
|
Insulating tsis kam |
6MΩ(500V) |
|
Voltage tiv taus |
AC 1.5kV 50HZ 1 min |
|
Kub thiab av noo |
0- + 40 degree , Tsawg dua lossis sib npaug li 85%RH |
|
Cia kub thiab av noo |
10 degree - + 50 degree, Tsawg dua lossis sib npaug li 90% RH |
|
Fais fab mov |
DC 12V lub zog tshwj xeeb |
|
Kev siv fais fab |
8W |
|
Dimension |
208 × 190 × 78mm3 |
|
Qhov hnyav |
Tsawg dua los yog sib npaug li 1 kg |
Khoom Feature Thiab Daim Ntawv Thov
1. Siv los ntsuas DC qhov tsis muaj ntawm Oxide Zinc ntes (voltage dependent resistor), cermet thib ob, thib peb electrode discharge tube, lub tshuab nqus tsev xob laim, thiab lwm yam khoom tiv thaiv dhau-voltage. Nws kuj tuaj yeem suav hais tias yog lub zog ruaj khov thiab lub zog hluav taws xob tas li.
2. Nrog HV luv luv Circuit Court tiv thaiv, dhau tam sim no tiv thaiv, high voltage preset, thiab ntau yam kev hloov pauv, HV tus kheej tawm lub sij hawm tsawg dua 0.5 vib nas this.
3. Nrog tus kheej-calibration muaj nuj nqi.
4. LCD zaub, siab precision, muaj zog ntseeg.
5. Ua ntej teeb tsa qhov ntsuas qhov ntsuas thaum ntsuas, yuav muaj lub tswb nrov yog tias tshaj qhov ntsuas qhov ntsuas.
6. Xaiv qhov ntsuas tsis tu ncua tuaj yeem ua qhov kev ntsuas tas li rau cov khoom siv ntsuas ntau.
7. Lub vaj huam sib luag muaj nuj nqi yog yooj yim thiab yooj yim rau kev khiav lag luam.
8. Lub teeb hauv qhov hnyav, yooj yim nqa.
Cov kab ntau lawm
Accessory
|
Serial Number |
Lub npe |
Tus nqi |
|
1 |
Mainframe |
ib |
|
2 |
Test kab (ib liab thiab ib tug dub, 1m) |
kaum ib |
|
3 |
Texter |
ib |
|
4 |
Hwj chim |
ib |
|
5 |
Aluminium alloy rooj |
ib |
|
6 |
Specification |
ib |
|
7 |
Daim ntawv tshuaj ntsuam xyuas |
ib |
|
8 |
Daim ntawv pov thawj |
ib |
