Khoom Taw Qhia
Tsis siv neeg rwb thaiv tsev roj tiv thaiv voltage tester yog tshawb fawb raws li tus qauv IEC-156 thiab GB507-2002 《Kev txiav txim siab ntawm dielectric zog ntawm insulating roj nthuav qhia, xav txog cov lus los ntawm cov neeg siv dav. Siv singlechip ua cov tub ntxhais, thiab txais yuav txoj kev sim uas tau teeb tsa thaum xub thawj thiab pib tom qab. Microcomputer khiav thiab tswj tag nrho cov txheej txheem txiav, yooj yim rau kev khiav lag luam thiab yooj yim rau kev siv.
Khoom Parameter
|
Lub zog ua haujlwm |
AC220V ± 10%, 50HZ ± 5% |
|
Kev ntsuas ntau |
AC {{0}}KV tus qauv (0 ~ 100kv yeem) |
|
Tsawg tam sim no |
5mA ua |
|
Kev ntsuas qhov tseeb |
1.50% |
|
Voltage tswj ceev |
2.5KV / S ± 10% |
|
Preset |
Sijhawm 1-9 |
|
Do lub sij hawm:0-1min39second |
|
|
Lub sij hawm sawv ntsug: 0-10min39second |
|
|
Kev ua haujlwm |
Kub: 0 degree -35 degree ; txheeb ze humidity: Tsawg dua los yog sib npaug li 75% |
|
Roj khob clearance |
2.5mm (Oil khob feeler txoj kab uas hla) |
|
Dimension |
415 × 315 × 315 hli |
|
Qhov hnyav |
28 Kg |
Khoom Feature Thiab Daim Ntawv Thov
- Nruab nrog qhov pib detective muaj nuj nqi, xws li nkag mus rau lub xeev pib dua sai li sai tau thaum pib, thiab ua kom voltage regulator rau xoom.
- Txais siv micro TPU-A vaj huam sib luag hom tshuab luam ntawv, luam tawm tau.
- Yuav kho lub sij hawm xeem, do thiab teem sij hawm, suab tswj thiab lub teeb tswj tsis tu ncua ceeb toom, luam ntawv los yog tsis-printing.
- Txais nws pib magnon do, tshem tawm cov nonuniform thiab npuas ntawm cov qauv roj.
Accessory
|
Serial Number |
Lub npe |
Tus nqi |
|
1 |
Mainframe |
ib |
|
2 |
Fuse |
plaub |
|
3 |
Roj khob |
ib |
|
4 |
Cov kab hluav taws xob |
ib |
|
5 |
Specification |
ib |
|
6 |
Daim ntawv tshuaj ntsuam xyuas |
ib |
|
7 |
Daim ntawv pov thawj |
ib |
Kev Tsim Nyog Kev Tsim Nyog
Daim ntawv tso cai ua lag luam
Calibration Certificate
ISO
Patent
FAQ
1. Kev xa khoom:Kev xa khoom sai thiab hloov pauv hom kev thauj mus los
2. Kev Them Nyiaj:Xaiv cov nqe lus them nqi thiab kev them nyiaj uas koj yooj yim
3. Kev muag khoom:24-teev kev sib cuag hauv online, Xaiv cov qauv tsim khoom raws li koj qhov kev thov, muab qhov zoo tshaj plaws, txhawb kev hloov kho
4. Lub sijhawm lav:Tag nrho cov tshuab zoo guarantees rau ib xyoos thiab lub neej kev pab txhawb nqa rau koj. Online teb rau cov neeg siv khoom 'kev teeb meem.
Neeg tuaj xyuas
Ntawm Qhov Chaw Pabcuam
Ntim nthuav dav
Peb qhov kev pabcuam
01
Kev pabcuam ua ntej muag
Ua kev sib tham txog cov khoom lag luam, kev tshaj tawm cov khoom lag luam, thiab kev ua lag luam, thiab kev txhawb nqa rau cov neeg siv khoom xav tau.
02
Kev pabcuam xa khoom
Ntim nrog ntoo rooj plaub, muab cov kev daws teeb meem sib txawv ntawm txoj kev xa khoom, txais kev them nyiaj sib txawv. Txuag tus nqi shipping thiab xyuas kom cov khoom tuaj txog zoo.
03
Kev pab cuam tom qab muag
Installation thiab commissioning ntawm tej yam khoom; Teb rau cov lus nug ntawm cov neeg siv khoom, teb cov lus nug ntawm cov neeg siv khoom, thiab daws cov lus nug ntawm cov neeg siv khoom.
Cim npe nrov: Tuam Tshoj ib khob transformer roj breakdown voltage tester, Tuam Tshoj ib khob transformer roj breakdown voltage tester manufacturers, lwm tus neeg, Hoobkas
